ENVE CUSTOM ROAD BIKE
ENVE CUSTOM ROAD BIKE
SKU:
PRODUCT DETAILS
After you reserve your spot in our production lineup, you can take your time customizing everything from geometry to paint color, and craft one-of-a-kind bike tailored to your needs.
An ENVE representative will work with you to finalize the details of your dream build and provide an estimated delivery date.
Custom Road Chassis starting at $8000.
BUILD SPECS
| CHASSIS | SRAM RED eTap AXS SES | SRAM FORCE eTap AXS SES |
Shimano Dura-Ace Di2 SES |
Shimano Ultegra Di2 SES |
|
| Frame/Fork | Custom Road | Custom Road | Custom Road | Custom Road | Custom Road |
| Wheelset | — | SES | SES | SES | SES |
| Handlebar | SES AR One-Piece Bar and Stem Custom Size |
SES AR One-Piece Bar and Stem Custom Size |
SES AR One-Piece Bar and Stem Custom Size |
SES AR One-Piece Bar and Stem Custom Size |
SES AR One-Piece Bar and Stem Custom Size |
| Stem | SES AR One-Piece Bar and Stem Custom Size |
SES AR One-Piece Bar and Stem Custom Size |
SES AR One-Piece Bar and Stem Custom Size |
SES AR One-Piece Bar and Stem Custom Size |
SES AR One-Piece Bar and Stem Custom Size |
| Seatpost | ENVE Integrated Seat Mast Topper | ENVE Integrated Seat Mast Topper | ENVE Integrated Seat Mast Topper | ENVE Integrated Seat Mast Topper | ENVE Integrated Seat Mast Topper |
| Saddle | SLR Boost Carbon, 130mm or 145mm | SLR Boost Carbon, 130mm or 145mm | SLR Boost Carbon, 130mm or 145mm | SLR Boost Carbon, 130mm or 145mm | SLR Boost Carbon, 130mm or 145mm |
| Tire | — | SES Road Tire (25, 27, 29, 31) |
SES Road Tire (25, 27, 29, 31) |
SES Road Tire (25, 27, 29, 31) |
SES Road Tire (25, 27, 29, 31) |
| Tire Sealant | — | Orange Seal, 4 Oz. | Orange Seal, 4 Oz. | Orange Seal, 4 Oz. | Orange Seal, 4 Oz. |
| Handlebar Tape | ENVE Black/Gray/White | ENVE Black/Gray/White | ENVE Black/Gray/White | ENVE Black/Gray/White | ENVE Black/Gray/White |
| Computer Mount | ENVE x K-Edge Aero | ENVE x K-Edge Aero | ENVE x K-Edge Aero | ENVE x K-Edge Aero | ENVE x K-Edge Aero |
| Bottle Cages | ENVE Carbon Road Cage | ENVE Carbon Road Cage | ENVE Carbon Road Cage | ENVE Carbon Road Cage | ENVE Carbon Road Cage |
| Rotor Lockring, CL F/R | — | ENVE, CL Inner | ENVE, CL Inner | ENVE, CL Inner | ENVE, CL Inner |
| Shifter/Brake L/R | — | Sram Red AXS | Sram Force AXS | Shimano Dura-Ace Di2 |
Shimano Ultegra Di2 |
| Front Derailleur | — | Sram Red AXS | Sram Force AXS | Shimano Dura-Ace Di2 |
Shimano Ultegra Di2 |
| Rear Derailleur | — | Sram Red AXS | Sram Force AXS | Shimano Dura-Ace Di2 |
Shimano Ultegra Di2 |
| Brake Rotor F/R | — | Sram Centerline 160 CL | Sram Paceline 160 CL | Shimano Centerlock Ice Tech RT-CL900 160 | Shimano Centerlock Ice Tech RT-CL800 160 |
| Crank | — |
Sram Red 46/33t, 48/35t, 50/37t 165mm, 170mm, 172.5mm, 175mm, 177.5mm |
Sram Force 46/33t, 48/35t 165mm, 170mm, 172.5mm, 175mm |
Shimano Dura-Ace 50/34t, 52/36t, 53/39t 165mm, 170mm, 172.5mm, 175mm, 177.5mm |
Shimano Ultegra 46/36t, 50/34t, 52/36t, 53/39t 165mm, 170mm, 172.5mm, 175mm |
| Bottom Bracket | — | 386EVO | 386EVO | 386EVO | 386EVO |
| Cassette | — | Sram Red, 10-26t, 10-28t, 10-33t | Sram Force, 10-26t, 10-28t, 10-33t, 10-36t | Shimano Dura-Ace, 11-25t, 11-28t, 11-30t, 12-25t, 12-28t | Shimano Ultegra, 11-25t, 11-28t, 11-30t, 11-32t, 12-25t |
| Chain | — | Sram Red | Sram Force | Shimano Dura-Ace | Shimano Ultegra |
| Battery Charger | — | Sram AXS Charger | Sram AXS Charger | Shimano Di2 Charger | Shimano Di2 Charger |
| MSRP $ USD | $8,000 | $15,240 | $13,894 | $14,810 | $13,872 |
| Frame Material | ENVE M.O.D Carbon |
| Fork Material | ENVE M.O.D Carbon |
| Target Application | Road Race/Performance or Endurance |
| Sizes (cm) | Custom (∼47cm, ∼50cm, ∼52cm, ∼54cm, ∼56cm, ∼58cm, ∼60cm; +/- 1cm) |
| Fork Rake | 55, 51, 47, 43, 39 (determined during fit) |
| Frame Weight | 850g +/- 2% (Size 56, Unpainted) |
| Headset | ENVE Integrated IS52/IS52 Internal Drop-In |
| Headset Bearing | 1.5″ IS52 Upper and Lower |
| Seat Post Diameter | ENVE Integrated Seat Mast Topper |
| BB Type | 386EVO |
| Brake Mount | Flat Mount |
| Front Axle | 12×100 (Total Length: 122, TP:1.5, TL:15) |
| Rear Axle | 12×142 (Total Length: 168, TP:1.0, TL:14) |
| Minimum Tire Size | 25c |
| Optimal Tire Size | 27c-32c |
| Maximum Listed Tire Clearance | 35c |
| Frame Routing | Internal |
