revoltcyclery

Basso Bikes ROAD SV

Name: Basso Bikes ROAD SV
Brand: revoltcyclery
Price: 12995.0 USD
Availability: InStock

Basso Bikes ROAD SV

SKU:

Sempre Veloce

Crafted by us, Perfected by you.

[From Latin «semper velocem»] meaning always fast: a philosophy where aerodynamics, lightness and handling are associated with comfort and adaptability capable of transforming every rider into the fastest version of themself.

Building a Rider-Focused Performance Bike

Without the constraints of catering firstly to professional racing demands, we had the freedom to design a bike that prioritizes the needs of everyday riders who ride for passion, performance, and the sheer love of the sport. By collaborating with 4 Performance Bike Fit Studio and leveraging artificial intelligence, we gained deep insights into what riders truly value: comfort, fit, and speed.

Whether you’re chasing your personal best, conquering challenging climbs, or simply savoring the joy of riding an Italian bike, the SV is engineered to elevate your cycling experience. This bike will transform every rider into the fastest version of themselves, delivering race-level performance to all.

Geometry

Every good bike fit starts with choosing the correct frame size for you. This will allow you to benefit best of the bike’s performance and comfort for an efficient riding position.

	45	48	51	53	56	58	61
Seat Tube (A1)	420 mm	455 mm	485 mm	505 mm	535 mm	550 mm	580 mm
Top Tube (B)	505 mm	515 mm	530 mm	546 mm	560 mm	575 mm	590 mm
Reach (R)	370 mm	375 mm	380 mm	385 mm	387 mm	389 mm	390 mm
Stack (S)	520 mm	521 mm	547 mm	560 mm	584 mm	609 mm	634 mm
Seat Tube Angle (C)	75,5°	75°	74,7°	74°	73,5°	73°	72,5°
Steering Tube Angle (D)	71,2°	71,5°	72°	72,5°	73°	73,5°	74°
Chain-Stay (E)	406 mm	406 mm	406 mm	406 mm	408 mm	412 mm	412 mm
Chain-Stay (F)	575 mm	578 mm	586 mm	591 mm	594 mm	599 mm	602 mm
Headtube (H)	115 mm	115 mm	140 mm	152 mm	170 mm	194 mm	218 mm
Wheelbase WB)	971 mm	974 mm	982 mm	987 mm	991 mm	999 mm	1002 mm
(S')Sloping	114 mm	82 mm	79 mm	75 mm	71 mm	83 mm	80 mm
Stand Over	722 mm	744 mm	772 mm	789 mm	810 mm	830 mm	857 mm
