Basso Bikes ROAD VENTA R

Basso Bikes ROAD VENTA R

Performance, Style, and Community

Venta R is our all-rounder performance road bike with modern lines and innovative features, created to inspire riders to engage with cycling, making premium and technological bikes accessible.

A bike that not only serves practical cycling ventures but also, connects with others with performance and style.

Shaped to dance through wind

Featuring aero-shaped tubes with a thoughtful balance that avoids extremes, the Venta R ensures agile handling in all riding scenarios, including challenging conditions like high winds.

Rear triangle

Its carefully crafted cut-out for the rear wheel paired with lowered seat stays, enhances aerodynamics, reducing drag and maximizing speed.

Fork design

Complementing this design, the straight-bladed fork delivers precise handling and responsive control, making every ride a thrilling and effortless experience.

Lightweight Construction

For the latest iteration of Venta R, we based the frame on Torayca T700 carbon fibers for both frame and fork paired with in mold bearing housing with no additional inserts.

This allows us to create a light and durable bike to enhance maneuverability making it easier for riders to handle across all frame sizes.

A PREMIUM PACKAGE



Groupset

Shimano 105 12 speed. Enjoy a wide gear range and enhanced ergonomics for a seamless ride, where shifting becomes second nature. Focus solely on the road ahead and let advanced technology elevate your cycling experience.

Wheels

Offering superior comfort and precise handling, even on rough surfaces, these wheels deliver unparalleled performance. Featuring a rim height of 27mm and an internal channel of 21mm, paired with crossed spoking lacing, Microtech MCT wheels provide exceptional strength and durability.

3B Clamp System Gen 2

A totally hidden fixing solution that is invisible on the frame, intertwining technological and aesthetic innovation.

The result is a lightweight, invisible and strong integrated system, which has been further implemented through the vulcanization of the steel plank. This Basso solution gives the 3B system an anti-vibration function, which improves the riding experience by elevating comfort on uneven and bumpy surfaces.

Heart Carbon seatpost

The seatpost seamlessly integrates with the frame and seatpost clamp, ensuring optimal comfort and performance. The bike comes equipped with a 15 mm setback Heart Carbon seatpost from Basso, with an additional 0 mm option available for purchase separately.

Cable management

Venta R features Microtech’s Integrated Cables Headset, the same used in all high tier Basso bikes.

The durability of the bearing is ensured by high quality seals while the cable guide design allows for effortless steering and precise handling.

Geometry

With an all-rounder geometry and higher sloping values on smaller sizes, the Venta R geometry ensures that riders can enjoy long rides without experiencing discomfort. This includes considerations for the handlebars, saddle, and overall frame design.

Bike Size 42 48 51 53 56 58 61
Seat Tube (A1) 420 mm 480 mm 510 mm 530 mm 560 mm 580 mm 610 mm
Top Tube (B) 505 mm 515 mm 525 mm 545 mm 560 mm 575 mm 590 mm
Reach (R) 371,9 mm 372 mm 375,4 mm 381,3 mm 383,1 mm 385,3 mm 386,6 mm
Stack (S) 534 mm 534 mm 558,5 mm 571 mm 579,5 mm 620,5 mm 645,4 mm
Seat Tube Angle (C) 76,5° 75° 75° 74° 73,5° 73° 72,5°
Steering Tube Angle (D) 71,8° 71,8° 72° 72,3° 73,5° 73,5° 74°
Chain-Stay Length (E) 404 mm 404 mm 404 mm 404 mm 406 mm 410 mm 410 mm
BB to Fork Length (F) 575,7 mm 575,8 mm 585,2 mm 592,2 mm 589,1 mm 589,1 mm 601,2 mm
Head Tube (H) 124 mm 124 mm 149 mm 161 mm 179 mm 203 mm 227 mm
Handlebar width C/C 400 mm 420 mm 420 mm 440 mm 440 mm 440 mm 460 mm
Stem Length 80 mm 90 mm 100 mm 110 mm 110 mm 120 mm 120 mm
Crank length 170 mm 170 mm 172,5 mm 172,5 mm 172,5 mm 172,5 mm 175 mm
$4,595.00 USD
$4,595.00 USD
Sale Sold out
Color: Magma black

In stock

View full details

Shipping Information

Shipping eligibility & rates are available at checkout. All Bikes are assembled and repacked for shipping.

Note: There are bikes that are not eligible for shipping due to manufacturer restrictions.

Contact us for special delivery request and quotes.

Free Shipping on all Apparel, Component and or Accessory orders over $150

Apply for synchrony financing
